SHACMAN F3000 6×4 Dump Truck | WP12.400 Euro II Engine | 400HP Enhanced Version Tipper Truck（For Ghana）
The SHACMAN F3000 6×4 dump truck (Enhanced Version, Model SX3255DU384) is engineered for demanding construction, mining, and bulk transport operations. Powered by the WEICHAI WP12.400E201 engine, it delivers 400HP and 11.6L displacement, ensuring strong performance and reliability under heavy loads.
This model is equipped with a 12-speed transmission, MAN 9.5T front axle, and a 16T MAN dual-stage rear axle (4.769 ratio), providing excellent traction, stability, and durability. Its robust chassis (850×300 mm) and reinforced multi-leaf spring suspension system further enhance load capacity and resilience in rough working conditions.
The F3000 medium-length flat roof cab is designed for practicality and comfort. It includes a hydraulic driver’s seat, four-point hydraulic suspension, single refrigeration air conditioning, steel bumper with lamp guard, manual windows, and a 165Ah maintenance-free battery. Safety features include dual hazard warning lights, water tank and taillight protection grilles, reversing buzzer, anti-theft fuel and battery systems, and WABCO four-channel ABS.
The upper body is configured with a 5600×2300×1500mm cargo box (floor thickness 8mm, side 6mm), front-lifting 180 cylinder, and standard heavy-duty fittings, making it ideal for transporting sand, gravel, and construction materials.
With its enhanced structure, powerful 400HP engine, and reliable SHACMAN build quality, the F3000 6×4 dump truck is a cost-effective and durable choice for fleet operators seeking efficiency in harsh environments.
| Platform | F3000 | |
| Drive type | 6×4 | |
| AEdition | Enhanced version | |
| Model | SX3255DU384 | |
|
Engine |
Model | WP12,400E201 |
| Horsepower | 400 | |
| Discharge | a surname Ⅱ | |
| Gear box | 12JSD200T-B–Iron Shell-QH 50 | |
| Cab | Medium-length flat roof cab has no top guide cover | |
| The highest speed (km/h) | 45-55 | |
| Chassis(mm) | 850×300（8+7） | |
| Wheelbase (mm) | 3775+1400 | |
| Axle speed ratio | 16 TMAN double-stage 4.769
16T MAN双级4.769 |
|
| Front axle | MAN 9.5T | |
| Suspension | Front and rear multi-piece reed four main piece + four horse-riding bolts | |
| Fuel tank | 380L iron oil tank | |
| Tires | 13R22.5 | |
|
Other configuration
|
F3000 middle-long fat-top cab without roofdeRectornydraulie main seat, four-point hydraulic mount, commorearview mirror, hot zone air conditioning, jack salecompressor, manual swing window machine, electricurnover, steel plate bumper, three-stage on-board pedals.mmon sleerng wheel, common side empty filter (mode230)commiexhaust. water tank protection grlleadlight protection grille, independent LED tail light withrotection grille,rear axle stability bar. 180Ahlaintenance-free Batery, No skylight with rear windowvithout curtain, anti-splash Fender, a high brightnessizard warning lamp on the top of the cab. two tnanglevarning signs,, engine with water coid treasure,WABeOnport four-channel ABS,cast front exlension beam +niddle traction hook, front-down protection, reversing(8kg).iron gas cvlinderion cap,120km’H | |
|
Upper configuration上 |
5600*2300*1500mm box, bottom 8 sides 6, before the domestic 180 cylinder, the field of the other standard | |
